| 型號 | TN2400 | TN2600 | TN2800 | |
|---|---|---|---|---|
| 8Ω立體聲功率 | 2X350W | 2X550W | 2X800W | |
| 4Ω立體聲功率 | 2X600W | 2X900W | 2x1200W | |
| 8Ω立體聲橋接功率 | 750W | 1150W | 1500W | |
| 輸出插座 | 4 Speakon Connectors | |||
| 頻響 |
20Hz-20KHz(+0/-0.5dB)
|
|||
| 信噪比 |
103dB
|
|||
| 總諧失真 |
<0.05%20Hz-20KHz
|
|||
| 輸入插座 | <0.1% | |||
| 連接插座 | 20K Ω balanced / 10K Ω unbalanced | |||
| 阻尼系數(shù) | Rear Panel:0.775V/1.0V/1.4V | |||
| 風扇 | 2 pcs temperature control cooling Fan | |||
| 功效保護 | Protection of short circuit,open circuit,overheat,DC,super sonic frequency etc | |||
| 前面板指示 | Protect indicator,signal indicator,work indicator | |||
| 電源要求 | 200-240v~50-60Hz | |||
| 包裝 |
435×370×90mm
|
|||
| 運輸尺寸 | ||||
| 凈重 | 17KG | 18KG | 19KG | |
| 毛重 | 19KG | 20KG | 21KG | |
